Rapid temperature change and humidity test chamber 504L (non-linear)

The rapid temperature change and humidity test machine, also known as the environmental test machine, tests various materials for heat resistance, cold resistance, dryness resistance and moisture resistance. It is suitable for testing the quality of electronic, electrical, communication, instrumentation, vehicle, plastic products, metal, food, chemical, building materials, medical, aerospace and other products.

Contact Supplier

Product Details

Rapid temperature and humidity heat test chamber (non-linear)

◆ scope of application

The rapid temperature and humidity test chamber, also known as an environmental test chamber, is a device used to evaluate the performance of materials under

various environmental conditions. It can test the heat resistance, cold resistance, dryness resistance, and moisture resistance of different materials. This equipment

is widely used in industries such as electronics, electrical appliances, mobile phones, communications, instruments, vehicles, plastic products, metals, food,

chemicals, building materials, medical, and aerospace, to ensure product quality.

◆ Product features

● The built-in mobile pulley is easy to move and place, and has a strong positioning screw to fix the position.

● The controller has multi-segment program editing and temperature and humidity can be controlled quickly or slope .

● The controller adopts imported LCD display screen, which can display the measured value, set value and time at the same time.

● It has an external water supply system, which is convenient for replenishing the water supply of the humidification tank and automatic recovery.

● The outer box is cold-rolled high-quality steel plate with spray paint, and the surface is phosphated and sprayed plastic treatment.

The inner box is SUS304# stainless steel 1.2mm

● The insulation material is polyurethane foam and ultra-fine glass fiber (thickness 100mm), which is environmentally friendly, safe, non-toxic and odorless.

● Reliable grounding protection device, leakage/circuit breaker protection, heater short circuit protection, studio over temperature alarm, refrigeration over

pressure/overload protection, power under voltage, over voltage, phase loss protection.

◆ technical parameter

product name	Rapid temperature and humidity heat test chamber (non-linear)
Product model	MRT-FTC-225-5N/10N/15N/20N	MRT-FTC-504-5N/10N/15N/20N	MRT-FTC-800-5N/10N/15N/20N	MRT-FTC-1000-5N/10N/15N/20N
Inner size (DWH) mm	500600750	700800900	80010001000	100010001000
External dimensions (DWH) mm	100011001800	120017502000	130015002000	150015002000
Volume （L）	225L	504L	800L	1000L
Power （W）	15KW～72KW
Temperature range	-70℃～+150℃
Range of rapid temperature change	-40℃~+85℃/-55℃~+85℃ (other temperature ranges can be customized)
Rate of temperature rise and fall	The heating and cooling rate is variable, and the whole heating and cooling rate is 5℃/min or 10℃/min or 15℃/min or 20℃/min on average
Supply voltage	AC380V±10% 50～60HZ
Temperature accuracy	0.1℃
Temperature fluctuation	±0.5℃
Temperature uniformity	±2℃
Humidity range	20%~98%RH (10%~98% RH/5%~98%RH are special selection conditions)
Humidity accuracy	±0.1%RH
Humidity uniformity	± 2.0%RH (humidity> 75%RH), ± 3.0%RH (humidity ≤ 75%RH)
Human-machine interface/controller	7-inch color touch screen and high performance programmable controller
Compression engine	France "Taikang" and Germany "GEA blog" Germany "Bizer"
Net weight (kg) (approx.)	360KG	550KG	630KG	680KG
Gross weight (kg) (approx.)	390KG	570KG	660KG	710KG
