Rapid temperature change test chamber (linear)

The rapid temperature change and humidity test machine, also known as the environmental test machine, tests various materials for heat resistance, cold resistance, dryness resistance and moisture resistance. It is suitable for testing the quality of electronic, electrical,communication, instrumentation, vehicle, plastic products, metal, food, chemical, building materials, medical, aerospace and other products.

Contact Supplier

Product Details

Rapid temperature change test chamber (linear)

◆ scope of application

The rapid temperature change test chamber, also known as an environmental test chamber, is a device used to evaluate the performance of materials under various

environmental conditions. It can test the heat resistance, cold resistance, dryness resistance, and moisture resistance of different materials. This equipment is

widely used in industries such as electronics, electrical appliances, mobile phones, communications, instruments, vehicles, plastic products, metals, food,

chemicals, building materials, medical, and aerospace, to ensure product quality.

◆ Product features

● The built-in mobile pulley is easy to move and place, and has a strong positioning screw to fix the position.

● The controller has multi-segment program editing and temperature and humidity can be controlled quickly or slope.

● The controller adopts imported LCD display screen, which can display the measured value, set value and time at the same time.

● It has an external water supply system, which is convenient for replenishing the water supply of the humidification tank and automatic recovery.

● The outer box is cold-rolled high-quality steel plate with spray paint, and the surface is phosphated and sprayed plastic treatment.

The inner box is SUS304# stainless steel 1.2mm

● The insulation material is polyurethane foam and ultra-fine glass fiber (thickness 100mm), which is environmentally friendly, safe, non-toxic and odorless.

● The compressor circulation system adopts the French "Tecsun" brand, which can more effectively remove the lubricating oil between the condenser tube and

capillary tube, and the whole series adopts environmental refrigerant (R23, R404)

● Reliable grounding protection device, leakage/circuit breaker protection, heater short circuit protection, studio over temperature alarm, refrigeration over

pressure/overload protection, power under voltage, over voltage, phase loss protection.

◆ technical parameter

产品名称

高低温湿热试验箱

产品型号

MRT-GDSR-50

MRT-GDSR-100

MRT-GDSR-150

MRT-GDSR-225

MRT-GDSR-504

MRT-GDSR-800

MRT-GDSR-1000

内胆尺寸(D*W*H)mm

350*350*410

400*500*500

500*500*600

500*600*750

700*800*900

800*1000*1000

1000*1000*1000

外形尺寸(D*W*H)mm

850*800*1600

850*900*1700

1000*1050*1800

1000*1100*1800

1200*1750*2000

1300*1500*2000

1500*1500*2000

温度范围

A：-20℃~+150℃ B：-40℃~+150℃ C：-60℃~+150℃ D：-80℃~+150℃

电源功率（W)

3KW

4KW

5KW

6KW

7KW

8KW

9KW

容积（L)

50L

100L

150L

225L

504L

800L

1000L

电源电压

AC220V±10% 50～60HZ

AC380V±10% 50～60HZ

湿度范围

20%～98%RH (10%～98%RH/5%～98%RH 为特殊选用条件)

湿度均匀度

±2.0%RH（湿度＞ 75%RH）， ±3.0%RH（湿度 ≤ 75%RH）

湿度精度

±0.1%RH

温度精度

±0.1℃

温度波动度

±0.5℃

温度均匀度

±2℃

环境温度

-5℃~35℃

人机界面/控制器

7寸彩色触摸式人机界面和高性能可编程控制器

升温/降温时间

升温速率：1℃~3℃/min，降温速率 0.7℃~1℃/min， (特殊升降温速率可定制)

压缩机

法国"泰康"和德国"GEA博客"德国“ 比泽尔 ”

水箱容积

15L/30L

补水方式

手动补水/自动补水

净重（kg）（约）

220KG

280KG

320KG

360KG

550KG

630KG

680KG

毛重（kg）（约）

240KG

300KG

350KG

390KG

570KG

660KG

710KG
