High and low temperature test chamber

The high and low temperature test machine is also known as the environmental test machine, which tests the heat resistance, cold resistance, dryness resistance and humidity resistance of various materials. It is suitable for electronic, electrical, communication, instrumentation, vehicle, plastic products, metal, food, chemical, building materials, medical, aerospace and other products to test the quality of products.

Contact Supplier

Product Details

High and low temperature test chamber

◆ scope of application

The high and low temperature test chamber, also known as an environmental test chamber, is a device used to evaluate the performance of materials under various

environmental conditions. It can test the heat resistance, cold resistance, dryness resistance, and moisture resistance of different materials. This equipment is

widely used in industries such as electronics, electrical appliances, mobile phones, communications, instruments, vehicles, plastic products, metals, food,

chemicals, building materials, medical, and aerospace, to ensure product quality.

◆ Product features

● The controller adopts imported LCD display screen, which can display the measured value, set value and time at the same time.

● The controller has multi-segment program editing and temperature and humidity can be controlled quickly or slope.

● It has an external water supply system, which is convenient for replenishing the water supply of

the humidification tank and automatic recovery.

● The outer box is cold-rolled high-quality steel plate with spray paint, and the surface is phosphated and sprayed plastic treatment.

The inner box is SUS304# stainless steel 1.2mm

● The insulation material is polyurethane foam and ultra-fine glass fiber (thickness 100mm), which is environmentally friendly, safe, non-toxic and odorless

● The built-in mobile pulley is easy to move and place, and has a strong positioning screw to fix the position.

● The compressor circulation system adopts the French "Tecsun" brand, which can more effectively remove the lubricating oil between the condenser tube and

capillary tube, and the whole series adopts environmental refrigerant (R23, R404)

● Reliable grounding protection device, leakage/circuit breaker protection, heater short circuit protection, blower motor overload protection, independent

overtemperature alarm of the working room, refrigeration machine overpressure protection, refrigeration machine overload protection, power undervoltage,

overvoltage, phase loss protection.

◆ technical parameter

产品名称

高低温试验箱

产品型号

MRT-GDW-50

MRT-GDW-100

MRT-GDW-150

MRT-GDW-225

MRT-GDW-504

MRT-GDW-800

MRT-GDW-1000

内胆尺寸(D*W*H)mm

350*350*410

400*500*500

500*500*600

500*600*750

700*800*900

800*1000*1000

1000*1000*1000

外形尺寸(D*W*H)mm

850*800*1600

850*900*1700

1000*1050*1800

1000*1100*1800

1200*1750*2000

1300*1500*2000

1500*1500*2000

温度范围

A：-20℃~+150℃ B：-40℃~+150℃ C：-60℃~+150℃ D：-80℃~+150℃

电源功率（W)

3KW

4KW

5KW

6KW

7KW

8KW

9KW

容积（L)

50L

100L

150L

225L

504L

800L

1000L

温度精度

±0.1℃

温度波动度

±0.5℃

温度均匀度

±2℃

环境温度

-5℃~35℃

人机界面/控制器

7寸彩色触摸式人机界面和高性能可编程控制器

升温/降温时间

升温速率：1℃~3℃/min，降温速率 0.7℃~1℃/min， (特殊升降温速率可定制)

压缩机

法国"泰康"和德国"GEA博客"德国“ 比泽尔 ”

水箱容积

15L/30L

补水方式

手动补水/自动补水

数据接口

标准RS485/RS232或以太网口等常用数据接口

净重（kg）（约）

220KG

280KG

320KG

360KG

550KG

630KG

680KG

毛重（kg）（约）

240KG

300KG

350KG

390KG

570KG

660KG

710KG
