High-low temperature alternating damp heat test chamber

The high and low temperature humidity test machine is also known as the environmental test machine, which tests the heat resistance, cold resistance, dryness resistance and humidity resistance of various materials. It is suitable for electronic, electrical, communication, instrumentation, vehicle, plastic products, metal, food, chemical, building materials, medical, aerospace and other products for quality testing.

Contact Supplier

Product Details

High - low temperature alternating damp heat test chamber

◆ scope of application

The high and low temperature alternating humidity test chamber, also known as an environmental test chamber, is a device used to evaluate the performance of

materials under various environmental conditions. It can test the heat resistance, cold resistance, dryness resistance, and moisture resistance of different materials.

This equipment is widely used in industries such as electronics, electrical appliances, mobile phones, communications, instruments, vehicles, plastic products,

metals, food, chemicals, building materials, medical, and aerospace, to ensure product quality.

◆ Product features

● The controller adopts imported LCD display screen, which can display the measured value, set value and time at the same time.

● The controller has multi-segment program editing and temperature and humidity can be controlled quickly or slope.

● It has an external water supply system, which is convenient for replenishing the water supply of the humidification tank and automatic recovery.

● The outer box is cold-rolled high-quality steel plate sprayed with paint, the surface is phosphated and sprayed with plastic treatment, and the inner box is

SUS304# stainless steel 1.2mm

● The compressor circulation system adopts French "Tecsun" brand, which can more effectively remove the lubricating oil between the condenser tube and

capillary tube, and the whole series adopts environmental refrigerant (R23, R404)

● Reliable grounding protection device, leakage/circuit breaker protection, heater short circuit protection, blower motor overload protection, independent

overtemperature alarm of the working room, refrigeration overpressure protection, refrigeration overload protection, power undervoltage, overvoltage, phase loss

protection.

◆ technical parameter

product name

High- low temperature alternating humidity heat test chamber

Product model

MRT-GDJS-50

MRT-GDJS-100

MRT-GDJS-150

MRT-GDJS-225

MRT-GDJS-504

MRT-GDJS-800

MRT-GDJS-1000

Inner size (D*W*H) mm

350*350*410

400*500*500

500*500*600

500*600*750

700*800*900

800*1000*1000

1000*1000*1000

External dimensions (D*W*H) mm

850*800*1600

850*900*1700

1000*1050*1800

1000*1100*1800

1200*1750*2000

1300*1500*2000

1500*1500*2000

Temperature range

A：-20℃～+150℃ B：-40℃～+150℃ C：-60℃～+150℃ D：-80℃～+150℃

Power （W）

3KW

4KW

5KW

6KW

7KW

8KW

9KW

Volume （L）

50L

100L

150L

225L

504L

800L

1000L

Supply voltage

AC220V±10% 50～60HZ

AC380V±10% 50～60HZ

Humidity range

20%~98%RH (10%~98% RH/5%~98%RH are special selection conditions)

Humidity uniformity

± 2.0%RH (humidity> 75%RH), ± 3.0%RH (humidity ≤ 75%RH)

Humidity accuracy

±0.1%RH

Temperature accuracy

±0.1℃

Temperature fluctuation

±0.5℃

Temperature uniformity

±2℃

Ambient temperature

-5℃～35℃

Human-machine interface/controller

7 color touch interface and high performance programmable controller

Heating/cooling time

Heating rate: 1℃~3℃/min, cooling rate 0.7℃~1℃/min, (special heating and cooling rate can be customized)

Compression engine

France "Taikang" and Germany "GEA blog" Germany "Bizer"

Tank volume

15L/30L

Water replenishment method

Manual water refill / automatic water refill

Net weight (kg) (approx.)

220KG

280KG

320KG

360KG

550KG

630KG

680KG

Gross weight (kg) (approx.)

240KG

300KG

350KG

390KG

570KG

660KG

710KG
